No.

Items

Unit

Details

1

Power type

Internal Combustion Power (Diesel)

2

Rated load

Kg

5000

3

Load center distance

mm

500

4

Maximum lifting height of fork shelf with blocking

mm

4260

5

Maximum lifting height

mm

3000

6

Full height of gantry fork landing, gantry vertical

mm

2358

7

Free lifting height

mm

132

8

Height of blocking rack (calculated from the fork surface of gantry)

mm

1196

9

Distance from seat surface to roof protection frame

mm

876

10

Full height of roof protection frame

mm

2304

11

Full length (without fork)

mm

3243

12

Front overhang distance

mm

589

13

Rear overhang

mm

565

14

Wheel base

mm

2100

15

Towing pin height

mm

375

16

Minimum ground clearance

mm

183

17

Full width

mm

1518

18

Fork pitch outside (max/min)

mm

1350/300

19

Track width (front/rear)

mm

1120/1196

20

Outside of minimum turning radius

mm

2887

21

Inside of minimum turning radius

mm

1958

22

Minimum right-angle radius width

mm

2987

23

Gantry tilt angle (front/back)

°

Front 6 / Rear 12

24

Fork size

mm

1070×50×150

25

Maximum driving speed (full load/no load)

Km/h

18/20

26

Speed increase (full load/no load)

mm/s

360/500

27

Speed decrease (full load/no load)

mm/s

550/450

28

Maximum traction (full load/no load)

KN

22

29

Maximum climbing capacity (full load/no load)

%

15/20

30

Total weight

Kg

6730

31

Weight distribution (full load front/rear)

Kg

10350/1340

32

Weight distribution (no load front/rear)

Kg

2920/3800

33

Number of wheels x/drive wheel

2X/2

34

Tire type (front/rear)

Pneumatic tire

35

Front tire

300-15

36

Rear tire

7.00-12

37

Service brake

Vacuum assist

38

Parking brake

Mechanical

39

Engine model

Quanchai 498

40

Reducer model

JDS45

41

Engine power

KW

60

42

Engine torque/speed

N.M

300N.M/1800r/min

43

Number of transmission shifts

2 forward / 2 reverse
